Robot Clock, v1.1.0

The electronic clock.

Support for the DS3231 chip and a colon as a separator between hours and minutes, update the dependencies, and perform refactoring.

Change Log

• components:
  • support for time counting made through the DS3231 chip;
• displaying:
  • support for displaying a blinking colon between hours and minutes:
    • support for setting an inverted voltage level;
• update the dependencies:
  • use the Robot Timer library;
  • use the Robot Button library;
  • update the Robot 7-segment Display library:
    • use the DisplayGroup structure;
• perform refactoring.

Features

• display the current time (hours and minutes only);
• working modes:
  • time counting;
  • hours setting;
  • minutes setting;
• components:
  • time counting is made through the following chips:
    • DS1302;
    • DS3231;
  • time displaying is made through the multiplexed LED display consisting of four 7-segment sub-displays;
  • controls:
    • working mode switching is made by a separate button;
    • hours and minutes incrementing is made by a separate button;
• displaying:
  • display a blinking separator between hours and minutes, selectable:
    • decimal point;
    • colon:
      • support for setting an inverted voltage level;
  • displaying on setting:
    • additionally display blinking hours on their setting;
    • additionally display blinking minutes on their setting.
